Any cause of hypercalcemia, most commonly primary or secondary hyperparathyroidism , can cause metastatic calcifications and abnormal pulmonary uptake. Metastatic osteosarcoma, neuroblastoma , radiation pneumonitis, and rarely bronchogenic carcinoma may demonstrate increased uptake of bone tracers. Accumulation of Tc-99m diphosphonate is also seen in pleural effusions, usually malignant.
CHEST UPTAKE
- Alveolar microlitiasis 1,2,3,4
- Artefact
- Aspergillosis
- Berylliosis
- Fibrothorax
- Hyperparathyroidism
- Hypercalcemia (ref) 8
- Hypervitaminosis D
- Idiopatic pulmonary ossification
- Infection (ref)9,10
- Liver transplant
- Lung carcinoma 11,12,13
- Metastases 14
- Mitral stenosis
- Neuroblastoma (ref)
- Pleural effusion (ref)
- Radiation therapy
- Sarcoidosis
- Tuberculosis
Primary hyperparathyroidism
The scintigrams (posterior (A) and anterior (B) projections) shows diffuse increased radionuclide uptake in the lungs and stomach, that represents metastatic calcifications, in a patient with parathyroid adenoma.
Osteosarcoma with pulmonary metastases
This bone scintigram in posterior projection demonstrates foci of abnormally increased radiotracer activity in the left hemithorax, in a patient with known osteosarcoma.
Neuroblastoma
This scintigram shows intense uptake in the mediastinum. Thirty-five to 74% of primary neuroblastomas accumulate bone agents, presumably secondary to dystrophic calcifications in the tumor.
Malignant pleural effusion
The bone scintigram (A) shows diffuse accumulation of the radiotracer in a malignant pleural effusion within the right hemithorax of this patient with lung carcinoma. A CT scan (B) confirms the presence of a right-sided pleural effusion.
Malignant pleural effusion
Anterior (A) and posterior (B) bone scintigrams show generalized increased radionuclide accumulation in the left hemithorax in this patient with lung carcinoma. A chest X-ray (C) confirms the presence of a left-sided pleural effusion.
Seminoma
(A) The bone scintigram in anterior projection demonstrates abnormally increased radionuclide activity in the mediastinum. There is a bulky soft tissue mass occupying the mediastinum on this axial CT (B) of the chest, that displaces the thoracic aorta posteriorly. The mediatinal mass is biopsy-proven seminoma.
Urine Contamination
(A) Initial bone scintigram in anterior projection shows several ill-defined areas of radiotracer accumulation that subsequently disappears on repeat scan (B) following decontamination.
- 1. [19471927] ""Sandstorm" image: bone scintigraphy in pulmonary alveolar microlithiasis." Eur J Nucl Med Mol Imaging. 2009;36:1353.
- 2. [3842281] "Bone scintigraphy in two siblings with pulmonary alveolar microlithiasis." Br J Radiol. 1985;58:763-6.
- 3. [1868666] "Role of bone scanning in pulmonary alveolar microlithiasis. Report of two cases." Clin Nucl Med. 1991;16:458-60.
- 4. [6460583] "Bone scintigraphy in pulmonary alveolar microlithiasis: a comparative study of radioactivity and density distribution." Clin Nucl Med. 1982;7:103-7.
- 5. [477167] "Diffuse lung uptake on bone imaging in primary hyperparathyroidism before and after excision of a parathyroid adenoma." Clin Nucl Med. 1979;4:382-3.
- 6. [428165] "Metastatic calcification in lungs and stomach demonstrated on bone scan in multiple myeloma." Clin Nucl Med. 1979;4:120-1.
- 7. [410253] "Uptake of bone imaging agents by diffuse pulmonary metastatic calcification." AJR Am J Roentgenol. 1977;129:871-4.
- 8. [8000405] "[Bone scintigraphy disclosing pulmonary hyperfixation in hypercalcemia]." Rev Rhum Ed Fr. 1994;61:60-2.
- 9. [7973760] "Unexpected pulmonary uptake of [99mTc]MDP in a patient with bronchopneumonia." Semin Nucl Med. 1994;24:246-7.
- 10. [2245122] "Pulmonary uptake of MDP: demonstration of site by correlation of emission and transmission computed tomography." West Engl Med J. 1990;105:43-6.
- 11. [2155083] "Pulmonary tumor associated with diffuse bilateral lung uptake of bone imaging agent." Clin Nucl Med. 1990;15:46-7.
- 12. [477149] "Accumulation of 99mTc-methylene diphosphonate in an adenocarcinoma of the lung." Clin Nucl Med. 1979;4:170-1.
- 13. [6247115] "Small cell carcinoma of the lung: primary site and hepatic metastases both detected on Tc-99m-pyrophosphate bone scan." Clin Nucl Med. 1980;5:260-2.
- 14. [6217611] "Pulmonary localization of phosphate bone agents in a case of metastatic breast carcinoma." Tumori. 1982;68:413-6.
